Electromagnetic Flowmeter

The Electromagnetic Flowmeter stands out for its high precision and reliability in monitoring liquid flow. Designed with a sleek digital display and crafted from durable black plastic, it ensures long-lasting performance even in demanding industrial and commercial environments. Equipped with a standard size structure, the flowmeter operates at a frequency of 50 Hertz (HZ) and is powered by electricity, ensuring consistent data accuracy and seamless integration into various systems. The innovative design combines easy usability with robust functionality, making it ideal for industries requiring efficient flow measurement solutions. Whether for industrial operations or commercial applications, this black-colored flowmeter offers unparalleled efficiency and durability.

Micro-controller based full bore type electromagnetic flow meters specially used for various industrial applications. These flow meters accurately measure the flow rate of conductive liquids & slurries in closed pipes. Due to its simple & rigid design, the flow meter is an obstruction-less & maintenance-free instrument in place of conventional mechanical flow measuring devices. The use of 'pulsed DC' technology offers highest ability & better measuring accuracy in the form of electrical signal 4-20 mA DC linearly proportional to volumetric flow. The instrument is based on Faraday's law electromagnetic induction. A magnetic field is generated by the instrument in the flow tube. The fluid flowing though this magnetic field generates a voltage that is proportional to the flow velocity. Corresponding electrical output is provided with respect to measuring flow range

FEATURE

• Full bore type
• Suitable for conductive liquids
• Universal Power Supply 85 to 265 VAC & 24 VDC
• Bi directional Flow rate
• Material option depending upon process data
• Local Indication through COG Display
• Easy maintenance as no moving parts
• Simple & cost effective construction
• Outstanding accuracy
• Inbuilt Relay status output (High / Low / Batch)
• 4 to 20 mA, Rs 485 & Pulse output
• Integral grounding

Specifications-

• Media : Liquids (Conductive)
• Conductivity : > 5 s/cm
• Viscosity : 200 cp max
• Excitation : Pulsed DC
• Line Size : 15 NB to 1000 NB
• Type of Output : 4 to 20mA DC, Modbus RS 485 & Pulse Output
• Display : COG Backlit
• Engineering Unit : User Programmable (m3 /Hr by default)
• Calibration Range : As per requirement (Factory calibrated for std. 2m/s velocity)
• Accuracy : +/- 0.5% of M.V. (for 20 to 100% flow)
• Linearity : +/- 0.5% of M.V.
• Repeatability : +/- 0.2% of M.V.
• Temperature Coefficient : +/- 0.05% per C
• Process Temperature : -20 to 85 C max for UPVC & Rubber Lining
• -20 to 100C for PTFE Lining
• Process Pressure : 10 kg/cm2 max (higher on request)
• Lining : No Lining / Hard Rubber / EPDM / PFA /PTFE
• Flange : UPVC / MS / SS316
• Electrode : SS 316L / Hastelloy C / Platinum / Titanium / Tantalum / Nickel
• Coil Housing : UPVC/ MS / SS 304 / SS316
• Power Supply : 85 to 265 VAC, 50 Hz & 24 VDC
• Power Consumption : < 10 VA
• Response Time : < 1 Sec
• Electronics : Integral / Remote
• Enclosure Protection : IP67
• Process connections : Flanged ANSI # 150 flanged, (Other on Requirement)
• Mounting : In-Line Horizontal / Vertical
• Operating Conditions : Temperature -20 to 55 C / RH 5 to 95% non-condensing
